Hot Starting & Oil leak : BX 19TZI Auto

BX Tech talk
PannyM
New Member
Posts: 12
Joined: Fri Jan 01, 2010 1:39 pm
Location: Southall

Hot Starting & Oil leak : BX 19TZI Auto

Post by PannyM »

BXers

I'm having problems :cry: restarting when the engine is hot. After 30-40 mins when the engine has cooled it'll start again.What can cause this?
I'll be cleaning the earth strap & connections to the engine & starter in the first instance.

I have noticed an oil leak near the oil filter that wasn't there before.
The filter is on tight. Could there be another source for such a leak?

All advice welcome :D as always. Panny
'I still haven't found what I'm looking for...!'
User avatar
electrokid
1K Away
Posts: 1764
Joined: Fri May 09, 2008 2:14 pm
Location: Woking

Post by electrokid »

Which engine ?
1992 BX19 TGD estate 228K Rusty - SORNed
2002 C5 HDi SX estate
Dollywobbler
Over 2k
Posts: 3940
Joined: Sun Dec 04, 2005 2:25 pm
Location: Wales

Post by Dollywobbler »

Petrol, 1905cc injection judging by the subject. Do these have coil packs? I'm a diesel man!
User avatar
Jaba
Over 2k
Posts: 2024
Joined: Tue Jul 05, 2005 7:54 am
Location: Usually in the garage
My Cars: BX GTi, C3 Auto
x 113

Post by Jaba »

From what you say about your next actions we may need more info please.
Do you mean that the starter does not turn the engine over or yes it turns over but will not start.
Does your car have a cat ?
The Joy of BX with just one Citroën BX to my name now. Will I sing Bye Bye to my GTI or will it be Till death us do part.
PannyM
New Member
Posts: 12
Joined: Fri Jan 01, 2010 1:39 pm
Location: Southall

Hot Starting & Oil leak : BX 19TZI Auto

Post by PannyM »

Jaba wrote:From what you say about your next actions we may need more info please.
Do you mean that the starter does not turn the engine over or yes it turns over but will not start.
Does your car have a cat ?
Yes the engine is a 1.9 injection.
Not sure if it has a CAT.What does it look like?

When COLD the starter turns & engine fires.

When HOT the starter will not turn.

On turning the key it clicks the display gauges operate. Then turning further the displays revert to zero at the point car should be starting.

After about an hour normal service resumes except it's not really normal is it?
'I still haven't found what I'm looking for...!'
User avatar
JayW
1K Away
Posts: 1590
Joined: Thu Dec 07, 2006 6:40 pm
Location: Now listen here you mullet...
x 13

Post by JayW »

I'd suggest the inhibitor on the gearbox...
I have zero patience for your tedium.
Linegeist
BXpert
Posts: 788
Joined: Thu Oct 27, 2005 6:35 pm
Location: Anglesey - out near the nuke power station!

Post by Linegeist »

Would that cause the displays to fail????? :? I thought the auto box's inhibitor switch simply open-circuited the starter energiser feed.

I'd rather suspect a seized starter solenoid - the frees off when cold.
User avatar
electrokid
1K Away
Posts: 1764
Joined: Fri May 09, 2008 2:14 pm
Location: Woking

Post by electrokid »

I'd rather suspect a seized starter solenoid - the frees off when cold.
I'd go with that as a first place to look as well.

Obviously check that connections to the starter are tight - you could check with a 12v bulb connected between the solenoid connection and the body that the solenoid is actually getting power when you try to start.

Had the problem on one of my Granadas - it turned out to be some muck in the solenoid itself. Magnetic materials - iron etc lose their ability to be magnetic with increasing temperature until a point is reached where they can't be magnetised at all - the curie point.

http://en.wikipedia.org/wiki/Curie_temperature

In the granny the muck was making it difficult for the solenoid to operate to the point where it was just capable of operating when the solenoid was cold - but when the solenoid was hot from the general heat of the engine the reduced magnetic effect was enough to prevent it working. I got it working once - having figured out what might be going on - stuck at the shops unable to start - I went back to the shops and bought a bottle of water from the fridge - poured it over the solenoid - and it started ok for me to get home.

The solenoid is only rated for intermittant operation so when you keep trying to start without success it gets even hotter and makes the situation worse.

You could isolate this problem by heating the solenoid with a hair dryer and then trying to start.

To fix, remove the starter motor and dismantle the solenoid (don't know how easy or not this is on a BX - there's different starter types anyway). Clean it thoroughly and reassemble it completely dry - no lubricants and no muck. Make sure that any bolts holding the magnetic circuit together (the iron around the coil etc) are as tight as you can reasonably get them (any muck or a gap in the magnetic circuit will reduce its effectiveness quite a bit).

Make sure everything is clean on reassembly and have a look at the brushes while you have the starter motor off.
1992 BX19 TGD estate 228K Rusty - SORNed
2002 C5 HDi SX estate
Mothman

Post by Mothman »

Should have read all the posts, sorry.

Andy
User avatar
electrokid
1K Away
Posts: 1764
Joined: Fri May 09, 2008 2:14 pm
Location: Woking

Post by electrokid »

Not sure if it has a CAT.What does it look like?
Sorry - couldn't resist...
Sadly, this one had to be re-homed after it learnt how to press ctrl+alt+del :-)
1992 BX19 TGD estate 228K Rusty - SORNed
2002 C5 HDi SX estate
User avatar
JayW
1K Away
Posts: 1590
Joined: Thu Dec 07, 2006 6:40 pm
Location: Now listen here you mullet...
x 13

Post by JayW »

Linegeist wrote:Would that cause the displays to fail?????
IIRC, the displays aren't energised with the ignition in the final (cranking) position so that would be normal.

Could be wrong, still hungover so anything's possible... :lol:
I have zero patience for your tedium.
User avatar
rayfenwick
1K Away
Posts: 1718
Joined: Sat Mar 27, 2010 9:16 am
Location: Kingston upon Hull

Post by rayfenwick »

[quote="electrokid"]

Gorgeous little thing. I have 3 kittens here at the moment, plus 3 adult cats. Lots of fluffy lunatics for entertainment :)
Ray

The Fleet (most recent first):
2000 Citroën XM 3.0 24V V6 Exclusive Auto (pre-MOT)
1997 Citroën XM 2.0 TCT Exclusive Auto (for sale)
1979 Citroën CX 2.4 EI Cmatic Prestige (slowly being restored)

1992 Alfa Romeo 164 Lusso 3.0 v6 12v Manual (on the to-do list)

www.citroencarclub.co.uk
User avatar
electrokid
1K Away
Posts: 1764
Joined: Fri May 09, 2008 2:14 pm
Location: Woking

Post by electrokid »

Unfortunately that's 'just' a webcat - I've been catless for a while now. I'm a bit concerned about the 'mainish' road close by and the fact that I usually end up with black tom cats with attitude :-) and toms have a much greater 'wandering range' than queens.

Panny - how are you getting on with the starting problem ?

I'm out-and-about this week and Southall is well within range - PM me if you'd like me to drop by with my can of freezer spray to check out your starter solenoid and to have a look in case it's something else - after all, 2 brains are better than one even if one of them is mine :-)
1992 BX19 TGD estate 228K Rusty - SORNed
2002 C5 HDi SX estate
User avatar
MULLEY
Over 2k
Posts: 8406
Joined: Thu Jun 22, 2006 11:10 pm
Location: Derbyshire
My Cars: 1999 Xsara LX 2.0HDI (90) Hatch - Fern
2002 C5 2.0 HDI (110) Estate - Jasmine - SORN
2011 Mini Cooper D Clubman - SOLD
2016 Mercedes A180D Sport - Auto refinement
1992 TZD Turbo - Bluebell - SORN
1992 TZD Turbo Estate - SORN
1991 Gti 16V - Blaze - crash damaged, will get repaired - SORN
1990 Gti 8Valve SOLD - looks like it's been scrapped
2002 Mini Cooper S - SOLD - i miss this car
1992 TXD - Scrapped in March 2014
1988 CX 25 GTI Turbo2 - SORN
1996 - AX Memphis 1.5D - Dream - SORN
x 8

Post by MULLEY »

Dog's rule, sorry guy's :lol:
2002 C5 2.0 HDI Estate - Jasmine - Now SORN
2011 Mini Cooper D Clubman - SOLD
2016 Mercedes A180D Sport - Auto refinement
1992 TZD Turbo - Bluebell - My daily
1991 Gti 16V - Blaze - crash damaged, will get repaired.
1990 Gti 8Valve SOLD - looks like it's been scrapped
2002 Mini Cooper S - SOLD - i miss this car
1992 TXD - Scrapped in March 2014
1988 CX 25 GTI Turbo2 - SORN
1996 - AX Memphis 1.5D - Dream - SORN

I'm not just a username, i'm also called Matthew.
User avatar
Tim Leech
Over 2k
Posts: 15629
Joined: Tue Apr 15, 2008 11:12 am
Location: Derbyshire
My Cars: Various
x 178

Post by Tim Leech »

My own 19TZI auto has started this problem, but wont go at all, starters being working when it felt like it for a while so may have to invest in one!
Lots of Motors, mostly semi broken....
